Pullback Capacity:
• Approximately 220 tons (about 440,000 lbs of pullback force)
Engine & Power:
• Usually powered by a diesel engine delivering roughly 350–400 HP (depending on configuration)
Rotational Torque:
• Delivers in the range of about 5,500–6,000 ft‑lb of torque for efficient makeup of drill joints
Hydraulic System:
• Operates at around 2,500 psi with an approximate flow rate of 55–60 gallons per minute
• Supports precise control of feed and rotary operations
Drill Rod & Pipe Handling:
• Designed with a rod carrying system that typically handles up to around 800 ft of drill rods
• Often configured with a drill stem rack available in various lengths (e.g., 10′ or 15′ options)
Control & Automation:
• Features an advanced digital control system that allows for fine‑tuning of drilling parameters and enhanced safety features
• May include automated rod loading options in certain configurations
Overall Rig Weight & Dimensions:
• Total machine weight is generally in the 30,000–35,000 lb range
• Engineered with a compact, rugged chassis for improved mobility and stability on job sites
