| Parameter | Specification |
| Hoisting Capacity | 1,000 tons (907,184 kg) |
| Motors | 2 × 1,150 HP AC Induction or Permanent Magnet |
| Total Installed Power | 2,300 HP |
| Maximum Speed | 250 RPM |
| Maximum Continuous Torque | 91,000 ft-lb (123,379 N·m) |
| Speed at Max Continuous Torque | 116 RPM |
| Maximum Breakout Torque | 150,000 ft-lb (203,372 N·m) |
| Maximum Makeup Torque | 120,000 ft-lb (162,698 N·m) |
| Static Lock Brake Capacity | 105,000 ft-lb (142,360 N·m) |
| Transmission Ratio | 6.9:1 |
| Water Course Bore | 3.75 in (95.3 mm) |
| Working Height | 22 ft (6.705 m) |
| Weight | 85,000 lb (38,555 kg) |
| Cooling | Water-cooled AC drive system |
| Control System | NOV AC Variable Frequency Drive |
| Elevator Link Ratings | Configurable up to 1,000 tons API |
| Washpipe Packing Rating | 7,500 psi (517 bar) |
| Pipe Handling | Integrated link tilt and pipe-handler system |
| Automation Ready | NOVOS compatible |
