Engine Type: V-12, 4-stroke-cycle diesel
Aspiration: Turbocharged and aftercooled
Displacement: 51.8 liters (3,161 in³)
Bore x Stroke: 170 mm x 190 mm (6.7 in x 7.5 in)
Compression Ratio: 13.0:1
Rotation (from flywheel end): Counterclockwise
Emissions: Non-certified (for use in non-regulated areas
Power Output: 761–1,119 bkW (1,020–1,500 bhp)
Rated Speed: 1,200–1,800 RPM
Maximum Torque: 6,210 Nm (4,580 lb-ft) @ 1,400 RPM
Cooling System: Gear-driven centrifugal water pump
Lube Oil System Capacity: 310.4 liters (327.9 quarts)
Cooling System Capacity: Approximately 156.8 liters (41.4 gallons)
Length: 2,676 mm (105 in)
Width: 1,703 mm (67 in)
Height: 1,720 mm (68 in)
Dry Weight: Approximately 6,078 kg (13,400 lbs)
Starting System: 24V electric starter
Charging System: 24V, 60A alternator
Air Inlet System: Dry-type air cleaner with service indicators
Fuel System: Cartridge-type fuel filters with service indicators
Instrumentation: Right-hand instrument panel with engine oil pressure gauge
Flywheel Housing: SAE No. 00 with 183 teeth flywheel
